SIRIUS 3RV2 motor starter protectors
4.9 Accessories
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
431
Locking
∅ 3,5 ... 4,5 mm


The mechanism can be locked inside the control cabinet with a padlock. The motor starter
protector must be set to the O position first, before the lock is attached.


The mechanism can also be locked outside the control cabinet via the handle.
In this case too, the motor starter protector must be set to the O position first, before the
locks are attached. The locking device on the handle is then pulled forward. Up to five
padlocks with a maximum shackle diameter of 6 mm or three padlocks with a maximum
shackle diameter of 8.5 mm can be attached to this locking device.
