SIRIUS 3RV2 motor starter protectors
4.9 Accessories
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
435
Mounting front plates
Table 4- 28 Mounting front plates
Step Operating instruction Figure
1 Insert the rotary operating mechanism into the
front plate.
2 Snap the motor starter protector onto the
holder.
3 Connect the motor starter protector.
4 Screw the front plate and the rotary operating
mechanism tight to the holder (use M3
screws).
M3





