SIRIUS 3RV2 motor starter protectors
4.9 Accessories
SIRIUS Innovations
444 System Manual, 01/2011, A8E56203870002-03
Mounting sequence
Note
The motor starter protector/feeder can be disassembled from the 8US busbar adapter either
before or after the 8US busbar adapter has been removed from the busbars.
Disassembly of the busbar adapter from the busbar system
The diagrams below illustrate how the busbar adapter is disassembled from the busbar
system:
Step Operating instruction Figure
1 From the front, insert a screwdriver
into the right-hand opening on the
busbar adapter and lock the
holder (A). The button on the top of
the busbar adapter should spring up.



$
