SIRIUS 3RV2 motor starter protectors
4.10 Technical data
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
473
"Self-protected combination motor controller (type E)" (up to 32 A)
3RV20 motor starter protector as "Self-Protected Combination Motor Controller (Type E)"
For approval according to UL 508, a clearance of 1 inch and a creepage distance of 2 inches
are required on the line side for a "Self-Protected Combination Motor Controller".
Therefore, 3RV20 motor starter protectors in size S00/S0 are approved according to UL 508
together with the terminal block (order no. 3RV29 28-1H) or phase barriers (order
no. 3RV2928-1K).
CSA approval does not require extended clearances and creepage distances. The terminal
blocks or phase barriers can, therefore, be omitted for use as a "Self-Protected Combination
Motor Controller" according to the CSA.
3RV20 motor starter protectors are approved as "Self-Protected Combination Motor
Controller" under the following file numbers:
● UL File No. E156943, CCN: NKJH.
● CSA Master Contract 165071, Product Class: 3211 08.
Motor starter protector hp-rating
1)
for FLA
2)
max.
Type V 1-phase 3-phase
Size S00
3RV20 11
115 1 2
200 2 3
230 2 5
460 -- 10
FLA
2)
max.
16 A, 480 V
12.5 A, 600 V
575 / 600 -- 10
Size S0
3RV20 21
115 2 5
200 3 7 1/2
230 5 10
460 -- 20
FLA
2)
max.
32 A, 480 V
575/600 -- --
1)
hp-rating= power in horse power(maximum motor power).
2)
FLA= Full Load Amps/motor full-load current
