System overview
1.7 Components and combinations
SIRIUS Innovations
50 System Manual, 01/2011, A8E56203870002-03
Accessories for 3RW30 soft starters
1 Link module to motor starter protector with screw-type terminals
2 Link module to motor starter protector with spring-loaded terminals (size S0)
3 Link module to motor starter protector with spring-loaded terminals (size S00)
4 Infeed terminal (sizes S00 and S0)
Figure 1-17 Accessories for 3RW30 soft starters
Accessories for 3RW40 soft starters
1 Link module to motor starter protector with screw-type terminals
2 Link module to motor starter protector with spring-loaded terminals
3 Infeed terminal
4 Sealing cover
5 Fan for increased switching frequency
Figure 1-18 Accessories for 3RW40 soft starters
