SIRIUS 3RA21/22 load feeders
6.11 Dimension drawings (dimensions in mm)
SIRIUS Innovations
628 System Manual, 01/2011, A8E56203870002-03







Figure 6-19 S0 direct-on-line starter, DC, hybrid connection system, link module 3RA2921-2FA00
Note
The versions of the fuseless load feeder (S0 direct-on-line starter, AC and DC) with hybrid
connection system are not available as 3RA2 pre-assembled combinations.







Figure 6-20 S0/S0 and S00/S0 reversing starters, AC, screw-type connection system
3RA2220-..B..-0AP0
