SIRIUS 3RA28 function modules for mounting on 3RT2 contactors
7.6 Mounting
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
661
Step Operating instruction Figure
1 Check that the interlock slide is
engaged in the uppermost position.

2 Attach the function module to the
contactor from the front.

3 Push the interlock slide down with a
screwdriver (3 mm blade width) until it
engages.

