Mounting
8.4 Disassembling devices from a level surface
3SK1 safety relays
128 Manual, 04/2013, A5E02526190021A/RS-AA/01
Procedure
Step Instructions Figure
1 Hold the device firmly.
2 Unscrew the cap screws.
3 Lift the device from the level
surface.
4 Remove the securing brackets
from the device.
Disassembling 17.5 mm and 22.5 mm devices
Disassembling 90 mm devices
