Connection
9.2 Devices 90 mm
3SK1 safety relays
172 Manual, 04/2013, A5E02526190021A/RS-AA/01
9.2.3 Connecting terminals
WARNING
Hazardous Voltage
Can Cause Death, Serious Injury, or Property Damage.
Before starting work, therefore, disconnect the system and devices from the power supply.
Procedure for screw-type terminal blocks
Step Instructions Figure
1 Insert the relevant cable into square on the
screw-type terminal until it engages.
2 Hold the cable in the screw-type terminal.
3 Tighten the screw of the terminal in which the
cable is inserted.
4 Pull on the cable to ensure it is screwed tight.
