3SK1 devices
5.2 3SK1 Advanced
3SK1 safety relays
72 Manual, 04/2013, A5E02526190021A/RS-AA/01
5.2.9.2 Design
① Top cover flap
② Top cover flap; internal inscription
③ Display LEDs
④ Potentiometer for setting the delay time
⑤ DIP switch
⑥ SET/RESET button
⑦ Bottom cover flap
⑧ Bottom cover flap; internal inscription
⑨ DataMatrix code
⑩ Device identification label
