Mounting
8.11 Removing 90 mm devices with device connectors from a standard mounting rail
3SK1 safety relays
142 Manual, 04/2013, A5E02526190021A/RS-AA/01
Procedure
Step Instructions Figure
1 Unlock the device using a
screwdriver
2 Pull the lower half of the
device away from the device
connector.
3 Unlock the device using a
screwdriver
4 Pull the device away from the
device connector
