Siemens SIRIUS 3SK1

Mounting
8.14 Mounting 90 mm devices with device connectors on the wall
3SK1 safety relays
154 Manual, 04/2013, A5E02526190021A/RS-AA/01
Step Instructions Figure
7 Mount output expansion
3SK1213 on the device
connectors
8 Mount all the devices required
for the system configuration in
accordance with the
respective installation
guidelines on the device
connectors
click
click
click
click
click
click
click
click
