Mounting
8.15 Removing 90 mm devices with device connectors from wall
3SK1 safety relays
156 Manual, 04/2013, A5E02526190021A/RS-AA/01
Procedure
Step Instructions Figure
1 Unlock the device (bottom)
using a screwdriver
2 Pull the lower half of the
device away from the device
connector
3 Unlock the device (top) using
a screwdriver
4 Pull the device away from the
device connector
