Configuration
3.1.12 RW (Rewind) Button
Pressing the RW button plays video backward at high speed. Pressing the button
again toggles the playback speed from , and . The screen displays
, and respectively.
Entering Fast Backward Playback mode from Live Monitoring mode can be
password protected.
3.1.13 PREV (Previous) Button
The PREV button only functions when playback video has been paused. Pressing
the PREV button plays video backward image-by-image.
3.1.14 Search/Stop Button
Pressing the Search/Stop button displays the Search menu. Pressing the button
again will exit the Search menu. This operation can be user password protected.
Pressing the Search/Stop button during Playback mode returns the DVR to the
Live Monitoring mode.
3.1.15 PLAY/PAUSE Button
Pressing the PLAY/PAUSE button plays back images at regular speed. Pressing
the button while in the playback mode will pause the video. The screen displays
when the DVR is playing back video. The screen displays
when in the Pause
mode.
Entering Playback mode from Live Monitoring mode can be user password
protected.
3.1.16 Next Button
The Next button only functions when playback video has been paused. Pressing
the Next button plays video forward image-by-image.
3.1.17 FF (Fast Forward) Button
Pressing the FF button plays video forward at high speed. Pressing the button
again toggles the playback speed from , and . The screen displays
, and respectively.
Entering Fast Playback mode from Live Monitoring mode can be password
protected.
3.1.18 REC (Record) Button
Press the REC button to set the DVR so that it is ready to record video, and
NOTHING will stop the recording, except an end of disk condition when the unit is
set to stop recording at the end of disk. A red dot appears on the screen when the
DVR is recording video. Press the button again to stop recording video. This
operation can be user password protected.
23
Siemens Building Technologies SISTORE AX9 AX16_EN.doc
Fire & Security Products 09.2004
