Operation
4.5 Playing Recorded Video
Once video has been recorded, you can view it by pressing the Play/Pause button.
When playing video for the first time, the DVR will display the most recent image.
When playing video subsequent times, the DVR will start playing video from the
last recalled image.
NOTE:
If the DVR is set in the Simplex mode, you will need to stop recording before playing back video.
When you return to the Live Monitoring mode, pressing the
REC button is required to start recording
again.
Pressing the Play/Pause button again will freeze the video on the screen.
4.5.1 Camera Buttons (1 to 16)
Pressing a camera button will display that camera full screen.
4.5.2 Display Button
Pressing the Display button during will cycle the display through the different
screen layouts. The display modes are: full, 4 x 4, 3 x 3, and 2 x 2 (not all formats
are available for the 9- and 4- channel DVRs).
NOTE:
You cannot change the display format while playing back video. Pause the video first, then change
the format.
4.5.3 RW (Rewind) Button
Pressing the RW button plays video backward at high speed. Pressing the button
again toggles the playback speed from , and . The screen displays
, and respectively.
Entering Fast Backward Playback mode from Live Monitoring mode can be
password protected.
4.5.4 PREV (Previous) Button
The PREV button only functions when playback video has been paused. Pressing
the PREV button plays video backward image-by-image.
4.5.5 Stop Button
Pressing the Stop button during Playback mode returns the DVR to the Live
Monitoring mode.
4.5.6 Next Button
The Next button only functions when playback video has been paused. Pressing
the Next button plays video forward image-by-image.
72
Siemens Building Technologies SISTORE AX9 AX16_EN.doc
Fire & Security Products 09.2004
