Operation
NOTE:
The time bar is in one-hour segments. If a segment is highlighted, it means that some video was
recorded during that hour. However, it does NOT mean video was recorded for the entire hour.
Once you have set the date and time you want to search, highlight the GO button
and press the
button. The selected date and time will display. The Play/Pause,
RW, FF, PREV, and Next buttons can now be used to review the surrounding
video.
4.6.4 Event Search
Fig. 79 Event Log screen.
The DVR maintains a log of each time the Alarm Input port is activated. The Event
Log screen displays this list. Use the arrow buttons to highlight the event for which
you would like to see video.
NOTE:
Event Search does not work when the data source is set to Search On Archive.
Pressing the
button will extract the event video and display the first image of the
event. Pressing the Play/Pause button will start playing the “event” video segment.
Pressing Stop returns to live monitoring. Pressing Search returns to the Event
Log.
You can also narrow your event search by selecting the Query… button and setting
up the new search condition.
75
Siemens Building Technologies SISTORE AX9 AX16_EN.doc
Fire & Security Products 09.2004
