Configuration
3.4 Quick Setup Screen
Fig. 19 Quick Setup screen.
The Quick Setup screen allows you to set up the most commonly used features of
your DVR. Use the arrow buttons to move through the options. Pressing the
button lets you make your selections.
NOTE:
If you enter the Quick Setup screen by entering User password, only Password setup will be
permitted.
z Highlight the box beside Quick Setup and press the button to toggle between
On and Off. If you select Off, you will use the Normal Setup screen to change
the DVR’s settings.
z Highlight the Record Speed box and select recording speeds from as few as one
image every 10 seconds to as fast as 50 ips PAL (60 ips NTSC).
z Highlight the Record Quality box and select from Very High, High, Standard and
Low.
z Highlight the box beside Audio Recording and select either On or Off.
NOTE:
It is the user’s responsibility to determine if local laws and regulations permit recording audio.
z Highlight the box beside Sequence Dwell Time and select from 3 to 60 seconds
for the camera sequence dwell time.
z Selecting System Information… enters that screen.
z Selecting Storage… enters a screen where you can check the storage status.
z Selecting Camera… enters a screen where you can set up camera information.
z Selecting Network Setup… enters a screen where you can set up network
information.
z Selecting Password… enters a screen where you will be able to change
passwords.
z Selecting Date/Time… enters a screen where you will be able to set the DVR’s
time and date.
z Selecting System Shutdown… shuts the DVR down. When shutting down the
DVR, you need to confirm that you want to shut down the unit, and you will be
asked for an administrator password.
25
Siemens Building Technologies SISTORE AX9 AX16_EN.doc
Fire & Security Products 09.2004
