Configuration
3.8.2 Alarm In Event Action (Alarm Out) Setup Screen
The DVR can be set to react to alarm events differently by activating an internal
buzzer or external alarms.
Fig. 49 Alarm In Event Action (Alarm Out) setup screen.
z Highlight the Sched box and press the button. A schedule screen appears.
Set the schedule as described earlier.
z Highlight the Alarm-Out box and select either Beep or the alarm output terminal
that you want to associate with the sensor.
z Highlight the Dwell box and set the length of time you want the output activated.
NOTE: When setting the Dwell to “0 sec”, the alarm output will be activated throughout the sensor
activation period, and inactive while the sensor is inactive.
48
Siemens Building Technologies SISTORE AX9 AX16_EN.doc
Fire & Security Products 09.2004
