Appendix H — Specifications
12 Appendix H — Specifications
VIDEO
Signal Format PAL or NTSC (selector switch)
Video Input Composite: 9 or 16 looping inputs, 1 Vp-p,
auto-terminating, 75 Ohms
Monitor Outputs Composite: One, 1 Vp-p, 75 Ohms
SVHS: One
Video Resolution
Standard: 336 x 272 (PAL), 336 x 224 (NTSC)
High: 672 x 272 (PAL), 672 x 224 (NTSC)
Playback/Record Speed
(images per second)
Standard Resolution: 50 ips (PAL), 60 ips (NTSC)
High Resolution: 25 ips (PAL), 30 ips (NTSC)
INPUTS/OUTPUTS
Alarm Input 9 or 16 TTL, NC/NO programmable, 4.3 V threshold,
using supplied Alarm I/O Board
Alarm Output 4 dry contact (open collector), 5 mA / 12 V,
30 mA / 5 V
Alarm Reset Input 1 dry contact, 4.3 V threshold,
using supplied Alarm I/O Board
Network Connectivity 10/100 Mbps Ethernet
RS232 for external modem
Audio Input One, “line in” or “mic” programmable
Audio Output One, “line”
CONNECTORS
Video Input Composite: 9 or 16 BNC
Video Loop Composite: 9 or 16 BNC
Monitor Output Composite: 1 BNC
SVHS: 1 Y/C
Audio In RCA connector
Audio Out RCA connector
Alarms / RS485 DB-25 male connector (with alarm I/O board)
Ethernet Port RJ-45
RS232 Serial Port DB-9 male connector
SCSI Port High-density UltraWide SCSI connector (68-pin)
USB Port USB connector
88
Siemens Building Technologies SISTORE AX9 AX16_EN.doc
Fire & Security Products 09.2004
