Appendix H — Specifications
STORAGE
Primary Storage EIDE hard disk drive (up to 2)
Secondary Storage SCSI hard disk drive (RAID)
Backup Storage USB hard disk drive
GENERAL
Dimensions (W x H x D) 16.9" x 1.7" x 15.7" (430 x 44 x 399 mm)
Unit Weight 14.3 lbs. (6.5 kg)
Shipping Weight 20.0 lbs. (9.1 kg)
Shipping Dimensions
(W x H x D)
21.3" x 12.1" x 20.1" (540 x 175 x 510 mm)
Operating Temperature 41 to 104°F (5 to 40°C)
Operating Humidity 0 to 90%
Power Supply 100 to 240 V AC, 1/2 A, 60/50 Hz
Auto ranging adapter included.
Input Voltage / Current 12 V DC / 5.8 A
Power Consumption 70 Watts Max.
APPROVALS
FCC FCC PART 15 Subpart B, Class A
CE EMI: EN55022, 1998, Class A
Safety: EN60950
Immunity: EN50130-4, 1998, Alarm Standard
Specifications are subject to change without notice.
89
Siemens Building Technologies SISTORE AX9 AX16_EN.doc
Fire & Security Products 09.2004
