3BHARDWARE CONFIGURATION AND INSTALLATION
4 Hardware configuration and installation
!
Warning notices
For configuration, installation, and commissioning, the specifications of the SIMATIC
manual apply. In this chapter you will receive additional information about the
hardware configuration, installation, and preparation for operation of SIWAREX U.
It is imperative to observe the safety instructions.
!
Warning
Unqualified interventions in the device/system or a failure to observe the warning
notices can result in serious injury or material damage. Therefore, only qualified
personnel are permitted to perform interventions on this device/system.
!
Warning
The device was developed, manufactured, tested, and documented observing the
relevant safety standards. Under normal circumstances, the device presents no
danger as regards material damage or the health of persons.
!
Danger
Commissioning is not permitted until it has been established that the machine in
which these components are to be installed meets the requirements of Directive
89/392/EEC.
4.1 Configuring the hardware in SIMATIC
SIWAREX U is a function module (FM) in the automation system SIMATIC S7 300.
It can be installed in all installation sites intended for function modules.
Use in SIMATIC S7 300 can take place in the central operation, in the extension
rack or peripherally in the ET 200M system.
Operation with SIMATIC S7 400 can only take place peripherally in the ET 200M
system. In this case, the active backplane bus can also be used.
4-10
SIWAREX U
