4BWEIGHING FUNCTIONS
5.6 DR 11 commands for channel 1, DR 12 commands for channel 2
In DR11/12 commands for SIWAREX U can be placed. Procedure:
o Write command number in DR11/12.
o Send DR 11/12 to the scale
o Check for data or command errors
Name Model Length Default Range of values/Meaning
Command code Int 2 0 Code of the command to be executed. See Chapter 6
Commands.
2
Table 5-4 Allocation of DR 11/12
For command list see Chapter 6 Commands.
5.7 DR 21 limit values channel 1, DR 22 limit values channel 2
In DR21 and/or DR22, the activation and deactivation values for the limit values
are parameterized.
Procedure:
o Check all parameters and modify as necessary.
o Send DR 21 and/or DR 22 to the scale.
Name Model Length Default Range of values/Meaning
Activation value
Limit value 1
SHORT 2 400 Activation point limit value 1
Deactivation value
Limit value 1
SHORT 2 220 Deactivation point limit value 1
Activation value
Limit value 2
SHORT 2 1000 Activation point limit value 2
Deactivation value
Limit value 2
SHORT 2 980 Deactivation point limit value 2
8
Table 5-5 Allocation of DR 21, DR 22
5.7.1 DR 21/22 – switch-on weight limit value 1
The switch-on and cut-off weight can be specified separately for each limit value.
In this way, both a minimum value monitor and maximum value monitor can be
realized by hysteresis.
5-36
