4BWEIGHING FUNCTIONS
Figure 5-4 Theoretical adjustment with SIWATOOL U
5.4 DR 5 General parameters
In DR5, parameters are specified which affect the module as a whole, i.e. which
have no connection to a measurement channel. Procedure:
o Check all parameters and modify as necessary.
o Send DR 5 to the scale
Name Model Length Default Range of values/Meaning
Module numbers BYTE 1 0 Each module can be assigned a module number.
Port parameters BYTE 1 0
This setting is valid both for the RS232 port and the TTY
port. The baud rate is fixed at 9600 bit/s.
Bit no. reset set
0 with parity bit (default) without parity bit
1 parity even (default) parity odd
2 - 7 reserve
Display type BYTE 1 0
Code (dec) Meaning
SIWAREX U 5-33
