Scale parameters and functions
8.3 DR 3 Calibration parameters
SIWAREX WP251
Manual, 12/2015, A5E37203357A
63
Parameter
Description
Format
Length
[bytes]
De-
fault
Min
Max
Write
protec-
tion
Modbus
holding
register
Minimum weighing range
(Page 67)
Minimum weight,
specification in numer-
ical increments
USHORT 2 0 0 65,535 x 1015
Maximum weighing range
(Page 67)
Maximum weight,
specification in weight
unit
FLOAT 4 100 >
(wr_min
*
num_in
cr)
9,999,9
99
x 1016
Calibration weights 0, 1, 2
and calibration digits 0, 1,
2 (Page 67)
Calibration weight 0 FLOAT 4 0 0 9,999,9
99
x 1018
Calibration weights 0, 1, 2
and calibration digits 0, 1,
2 (Page 67)
Calibration weight 1 FLOAT 4 100 0 9,999,9
99
x 1020
Calibration weights 0, 1, 2
and calibration digits 0, 1,
2 (Page 67)
Calibration weight 2 FLOAT 4 0 0 9,999,9
99
x 1022
Calibration digits 0
(measured)
Calibration digits 0
determined during
calibration with cali-
bration weight 0
LONG 4 0 -
3,999,9
99
3,999,9
99
x 1024
Calibration digits 1
(measured)
Calibration digits 1
determined during
calibration with cali-
bration weight 1
LONG 4 2,000
,000
0 3,999,9
99
x 1026
Calibration digits 2
(measured)
Calibration digits 2
determined during
calibration with cali-
bration weight 2
LONG 4 0 0 3,999,9
99
x 1028
Scale interval (Page 68) Resolution of weighing
range1 (1*10**k,
2*10**k, 5*10**k]; k: -4
… 1 )
FLOAT 4 0.1 0.0001 50.0 x 1030
Zero by power-on
(Page 68)
0: Deactivated
1: Activated
BOOL 0 0 0 1 x 1032
Zero by power-on when
tare ≠ 0 (Page 68) 0: No initial zeroing
when tare weight ≠ 0
1: Initial zeroing when
tare weight ≠ 0
BOOL 0 0 0 1 x 1032
Automatic zero adjust-
ment (Page 68)
0: Deactivated
1: Activated
BOOL 0 0 0 1 x 1032
Subtractive / additive tare
device (Page 69)
0: Subtractive
1: Additive
BOOL 0 0 0 1 x 1032
Weight simulation allowed
(Page 69)
0: Not enabled
1: Enabled
BOOL 0 0 0 1 x 1032
