Siemens SIWAREX WP251 User Manual

Scale parameters and functions
8.3 DR 3 Calibration parameters
SIWAREX WP251
Manual, 12/2015, A5E37203357A
65
Parameter
Description
Format
Length
[bytes]
De-
fault
Min
Max
Write
protec-
tion
Modbus
holding
register
Max. waiting time for
standstill 1 (Page 72)
Max. waiting time until
standstill 1.
0: Standstill-
dependent scale
command is rejected
immediately if no
standstill.
>0: Maximum waiting
time until a technology
message is issued.
TIME 4 0 0 10,000 - 1048
Standstill 2 - range
(Page 73)
Standstill range 2,
specification in numer-
ical increments
FLOAT 4 1 0 0 x 1050
Standstill 2 - time
(Page 73)
Standstill time 2 (ms) TIME 4 1000 10 10,000 x 1052
Setting time before
standstill 2 (Page 73)
Settling time before
standstill 2 is evaluat-
ed (ms)
TIME 4 0 0 10,000 - 1054
Frequency low pass filter
1 (Page 74)
Low-pass filter limit
frequency:
0: Filter disabled
FLOAT 4 2 0 50 x 1056
Order no. low pass filter 1
(Page 74)
Filter order number 1
to 10
USHORT 2 4 1 4 x 1058
Depth average filter
(Page 74)
Depth of first average
filter (0=inactive)
USHORT 2 20 0 250 x 1059
Reserve
Reserve
USHORT
2
20
0
20
-
1060
Weighing operating mode
(Page 75)
0: NAWI – Filling
1: NAWI – Removal
10: Gravimetric-Filling
20: Catchweighing – F.
21: Catchweighing-R.
USHORT 2 20 0 20 x 1061
Resolution of master
totalizer
Resolution of sums
(1*10**k, 2*10**k,
5*10**k]; k: -4 … 1 )
FLOAT 4 0.1 - - - 1062
Reserve
Reserve
FLOAT
4
0
-
-
-
1064
SecureDisplay including
weighing range data
(Page 75)
Display weighing
range data in Se-
cureDisplay
0: No
1: Yes
USHORT 2 0 - - - 1066
SecureDisplay interface
(Page 75)
0: SecureDisplay
directly at WP251
Ethernet port
1: SecureDisplay at
S7-1200 Ethernet port
USHORT 2 0 - - - 1067
String header version
SecureDisplay
String header version
SecureDisplay
UBYTE 2 12,
12
- - - 1068
