Scale parameters and functions
8.8 DR 7 Process interfaces
SIWAREX WP251
88 Manual, 12/2015, A5E37203357A
Variable
Note
Type
Length
(bytes)
RW
Default
Min.
Max.
Modbus
Register
Input filtering
(hardware
setting)
(Page 91)
0: 0.2 ms
1: 0.2 ms
2: 0.4 ms
3: 0.8 ms
4: 1.6 ms
5: 3.2 ms
6: 6.4 ms
7: 12.8 ms
USHORT 2 rw 5 0 7 1308
Assignment of
digital output
DQ.0, DQ.1,
DQ.2, DQ.3
(Page 91)
Assignment for output 0:
Code 0 … 0x1F hex: Bit
no. of the status flags
from byte 0 to 3 (DR 30)
Code 0x21 hex: Data
record 18
Code 0x22 hex: S7 I/O
modules
Code 0xFF hex: Output
always disabled
USHORT 2 rw 0 0 0xFFFF 1309
Assignment for output 1:
(see output 0)
USHORT 2 rw 0 0 0xFFFF 1310
Assignment for output 2:
(see output 0)
USHORT 2 rw 0 0 0xFFFF 1311
Assignment for output 3:
(see output 0)
USHORT 2 rw 0 0 0xFFFF 1312
Response of
digital outputs
to faults or
SIMATIC
STOP
(Page 92)
Response of digital out-
puts following module
fault or CPU STOP:
0: Outputs are switched
off
1: Outputs are not
switched off, continue
2: The relevant substitute
value is activated
3: The outputs are
switched on
USHORT 2 rw 0 0 0 1313
Substitute
value for DQ
0, 1, 2, 3 fol-
lowing fault or
SIMATIC
STOP
(Page 92)
Substitute value for DQ 0
following fault or SIMATIC
CPU STOP
BIT 0 rw 0 0 1 1314.16
Substitute value for DQ 1
following fault or SIMATIC
CPU STOP
BIT 0 rw 0 0 1 1314.15
Substitute value for DQ 2
following fau
lt or SIMATIC
CPU STOP
BIT 0 rw 0 0 1 1314.14
Substitute value for DQ 3
following fault or SIMATIC
CPU STOP
BIT 0 rw 0 0 1 1314.13
Bit 4
Reserve
BIT
0
rw
0
0
1
1314.12
Bit 5
Reserve
BIT
0
rw
0
0
1
1314.11
