Description
10 Monitored output 1 : select the operation
01 Processing as “Sounders” (see step 05 and paragraph 12.1)
Active until “Silence/Re-sound” or “Reset” via non-monitored control input 1
99 Do not use this option
11 Monitored output 2 : select the operation
01 Processing as “RT-alarm” (see step 06 and paragraph 12.1)
02 Processing as “Fire controls A” (see paragraph 12.1)
03 Processing as “Fire controls B” (see paragraph 12.1)
04 Processing as “Fire controls C” (see paragraph 12.1)
05 Processing as “Sounders” (see steps 05 and 10 and paragraph 12.1)
06 Processing as “Sounders” (see steps 05 and 10 and paragraph 12.1), except that:
- is activated continuously in state “Activated”
- is deactivated in state “Emergency Hold/Abort”
Application: additional wire for second tone sounder
07 Active in state “Mechanical blocked”
Application: use of a specific Warning Panel showing that extinguishing is blocked
08 Active in state “Automatic blocked” or “Manual blocked”
Application: specific Warning Panel for “Manual Blocked” or “Automatic Blocked”
09 Active in state “Automatic blocked” and “Manual blocked”
Application: specific Warning Panel for “Manual Blocked” and “Automatic Blocked”
99 Not used (no EOL required)
12 Monitored output 3 : operation
Fire alarm Evacuation Released
01 Not activated Continuous Continuous until "Reset"
02 Not activated Pulsating Continuous until "Reset"
03 Not activated Pulsating Continuous until “key 4” is pressed after "Reset"
04 Pulsating Continuous Continuous until "Reset"
05 Not activated Pulsating Pulsating until "Reset"
99 Not used (no EOL required)
13 Monitored output 4 : operation
01 Processing as “Actuators”, activated at the end of the pre-discharged warning time
02 Processing as “Actuators”, activated at the beginning of the pre-discharged warning time
Application: activation of a pneumatic delay device
14 Monitored output 5 : operation
01 Processing as “Actuators”, activated at the end of the pre-discharged warning time (see step 02 and paragraph 12.1)
02
Processing as “Actuators”, activated at the beginning of the pre-discharged warning time (see step 02 and paragraph 12.1)
03 Processing as “Fire controls A” (see paragraph 12.1)
04 Processing as “Fire controsl B” (see paragraph 12.1)
05 Processing as “Fire controls C” (see paragraph 12.1)
06 Processing as “Fire control", activated 5s before the end of the pre-discharged warning time (see paragraph 12.1)
07 Processing as “Fire control", activated 10s before the end of the pre-discharged warning time (see paragraph 12.1)
08 Processing as “Fire control", activated 15s before the end of the pre-discharged warning time (see paragraph 12.1)
09 Processing as "Extract fan" (see paragraph 12.1)
10 Processing as "Fire damper" (see steps 63 and 64 and paragraph 12.1)
11 Processing as "Door holder" (see paragraph 12.1)
12 Active in state “Mechanical Blocked”
Application: use of a specific Warning Panel showing that extinguishing is blocked
