Connection to Sinteso / Cerberus PRO panels
91
Building Technologies A6V10257473_e_en_--
Fire Safety 2015-03-04
Sinteso / Cerberus PRO operating terminal when the “XC10 zone” element
4:Input ‘Blocked’ is activated
- Resetable from Sinteso / Cerberus PRO
If this option is selected, the “XC10 zone” element 1:Output ‘Reset’ is activated
for 3 seconds each time a “Reset” command is operated from the Sinteso /
Cerberus PRO panel.
- Enable / Reset time:
If this option is selected, the Sinteso / Cerberus PRO panel checks inputs
“Discharged” and “Pre-alarm” during the “Reset time”. If these inputs are back
to the normal condition, the Sinteso / Cerberus PRO panel is reset. For a proper
operation, “Reset time” must be always set to 10s.
Usually, “XC10 zone” input elements are assigned to FDCIO222 module inputs.
Depending on FDCIO inputs status, the following messages are displayed on
Sinteso / Cerberus PRO panel:
“XC10 zone”
input
FDCIO
Input
assigned
Message displayed on Sinteso / Cerberus PRO panel
Short circuit 1k15 3k01 1k15 + 3k01 Line open
“Discharged” IN1
“XC10 zone
Exting.
discharged”
“XC10 zone
Exting.
discharged”
(normal) (normal)
“IN1 Fault”
“Fault” IN2
(normal)
“XC10 zone
Fault”
“XC10 zone
Fault”
“XC10 zone
Fault”
“XC10 zone
Fault”
“Pre-alarm” IN3
“XC10 zone
Exting.pre-
alarm”
“XC10 zone
Exting.pre-
alarm”
(normal) (normal)
“IN3 Fault”
“Blocked” IN4
“XC10 zone
Aut+man
ext.OFF XC”
“XC10 zone
Aut+man
ext.OFF XC”
(normal) (normal)
“XC10 zone
Aut.ext.OFF
XC”
18.2 Detectors connected to XC10 panel
18.2.1 Connections variant 1
Following XC10 zone messages can be displayed:
- “Exting. discharged”
- “Fault”
- “Exting.pre-alarm”
- “Aut+man ext.OFF XC”
- “Aut.ext.OFF XC”
- “Aut+man ext.OFF FC” (XC10 blocked from the Sinteso / Cerberus PRO panel)
- “Aut.ext.OFF FC” (XC10 blocked from the Sinteso / Cerberus PRO panel)
Following controls are possible from the Sinteso / Cerberus PRO panel:
- Reset
- Block autom.+manual
- Block autom.
