Siemens XC1005-A User Manual

Programming
71
Building Technologies A6V10257473_e_en_--
Fire Safety 2015-03-04
01 One second beep at each "Emergency hold/abort" change
02 Pulsated until "Silence buzzer"
40 Pre-activated condition: select the function in case "Automatic blocked" operation
01 Alarm on one of the extinguishing triggering zones = "Fire alarm" + "Pre-activated" until "Automatic blocked" condition is
cancelled or "Reset"
02 Alarm on one of the extinguishing triggering zones = "Fire alarm" until "Automatic blocked" condition is cancelled or "Reset"
41 Automatic/Manual blocking: standard or alternative display
01 Standard (EU) : LED 14 = "Manual blocked", LED 15 = not used, LED 16 = "Automatic blocked"
02 Alternative (UK) : LED 14 = "Manual blocked", LED 15 = "Automatic & manual", LED 16 = "Automatic blocked"
42 Discharged contact: select the display in case the contact is not activated within 30s after the gas release
01 "Released" led flashes slow
1)
02 "Released" led flashes fast
1)
+ "Fault"
1)
03 "Released" led is not activated
2)
+ "Fault"
1)
04 "Released" led is not activated
2)
1)
The corresponding relay contacts and/or driver outputs are activated
2)
The corresponding relay contacts and/or driver outputs are not enabled
43 Loss of agent: select the display during flooding time
01 Indicated after "Released"
02 Indicated after "Reset"
Application: "Loss of agent" is normal after a release and do not correspond to a gas leakage
12.12 Steps 44 to 47 - Faults
Step
O
p
tion
Description
44 Fault display
01 Immediate (any fault)
02 Indication is 15 s delayed for zone, monitored IOs (except for “Emergency hold” and “Emergency
abort”), loss of agent and incorrect position
45 Fault reset
01 Faults must not be reset
02 Faults must be reset
03 “Mains” fault and “Loss of agent” fault indication automatically disappear as soon as the fault is repaired, even if the buzzer
was not acknowledged
46 Batteries fault
01 Indicated
02 Not indicated (not EN 12094-1 and EN 54-2 compliant)
47 Mains fault
01 Indicated immediately
02 Indicated after 3 minutes
03 Indicated after 10 minutes
04 Indicated after 30 minutes
05 Indicated after 3 hours (not EN 12094-1 and EN 54-2 compliant)
12.13 Steps 48 to 51 - Non monitored control inputs 1 to 4
Step
O
p
tion
Description
48 Non monitored control input 1
01 "Reset"
2) 3)
49 Non monitored control input 2
01 "Silence buzzer"
2)
02 "Automatic blocked"
1) 3)
