Sierra Wireless FX30S User Guide
Rev. 7 August 2021 46 41110485
Table 3-6: FX30S Radio Module WP7611-1
Radio Technology Band Frequency (Tx) Frequency (Rx)
LTE Band 2 1850–1910 MHz 1930– 1990 MHz
Band 4 1710–1755 MHz 2110–2155 MHz
Band 5 824–849 MHz 869–894 MHz
Band 12 699–716 MHz 729 –746 MHz
Band 13 777–787 MHz 746–756 MHz
Band 14 788–798 MHz 758–768 MHz
Band 25 1850–1915 MHz 1930–1995 MHz
Band 26 814–849 MHz 859–894 MHz
Band 66 1710–1780 MHz 2110–2200 MHz
Band 71 663–698 MHz 617–652 MHz
UMTS Band 2 1850–1910 MHz 1930–1990 MHz
Band 4 1710–1755 MHz 2110–2155 MHz
Band 5 824–849 MHz 869–894 MHz
Table 3-7: GNSS Bands Supported
Band Frequency
GPS L1 1575.42 MHz
GLONASS L1 FDMA 1602 MHz
Galileo E1 1575.42 MHz
BeiDou (WP7702/WP7611-1) 1561.098 MHz
QZSS (WP7611-1) 1575.42 MHz
