Specifications
Rev. 7 August 2021 55 41110485
Table 3-13: Power Consumption — Active Mode FX30S Cat-M (WP7611-1)
Mode Conditions Voltage Max continuous Burst
V mA mW mA mW
Active Idle
USB and Serial cables are
unplugged
24 20 482 219 5267
12 35 424 494 5925
4.5 77 348 1244 5596
Active Full
Function LTE
Max Tx power (+33 dBm)
USB 57 Mbps
Serial connected
24 169 3839 290 6960
12 290 3479 657 7888
4.5 739 3325 1649 7424
Active Full
Function
HSDPA
Max Tx power (+33 dBm)
USB 57 Mbps
Serial connected
24 163 3924 290 6960
12 297 3563 657 7888
4.5 758 3413 1650 7424
Table 3-14: Power Consumption — Off and Ultra Low Power Modes (all
FX30S variants)
Mode Conditions Voltage Maximum continuous
V
µA
a
a. The FX30S protection circuitry results in the increase in current as voltage increases.
µW
Off On/Off is set to Off 24 71 1697
12 36 436
5 16 78
Ultra Low Power Triggering timer 24 351 8414
12 172 2059
5 168 842
