Sierra Wireless FX30S User Guide
Rev. 7 August 2021 44 41110485
Radio Frequency Bands
Mechanical Specifications
For mechanical drawings, dimensions, and
weight, see Mechanical Specifications on
page 49.
• Housing—The FX30S is made of ruggedized powder-coated
aluminum.
• RoHS2—The FX30S complies with the Restriction of
Hazardous Substances Directive 2011/65/EU (RoHS2). This
directive restricts the use of hazardous materials in the
manufacture of various types of electronic and electrical
equipment.
Screw Torque Settings • Mount screws
1.1 N-m (10 in-lb)
• Antennas
Finger tight (5–7in-lb.) is sufficient and the max torque should
not go beyond 1.1 N-m (10 in-lb).
Operating Voltage 4.75 to 32 VDC
GNSS Technology Satellite channels
available
Acquisition: 118
Simultaneous tracking: 40
Support for
predicted orbits
Yes
Predicted orbit CEP-
50 accuracy
5 meters
Constellations See Table 3-7 on page 46.
GNSS Message
Protocol
NMEA
Standalone Time to
First Fix (TTFF)
• Hot start: 1 second
• Warm start: 29 seconds
• Cold start: 32 seconds
Sensitivity Standalone MS-based tracking sensitivity: -161 dBm
Cold start sensitivity: -145 dBm
MS-assisted GNSS acquisition sensitivity: -158 dBm
Table 3-1: Specifications (Continued)
Table 3-4: FX30S Radio Module WP8548
Radio Technology Band Frequency (Tx) Frequency (Rx)
HSPA+ Band 1 1920–1980 MHz 2110–2170 MHz
Band 2 1850–1910 MHz 1930–1990 MHz
Band 5 824–849 MHz 869–894 MHz
Band 6 830–840 MHz 875–885 MHz
Band 8 880–915 MHz 925–960 MHz
Band 19 830– 845 MHz 875–890 MHz
