Radio Module Conducted Transmit Power
The following tables provide radio module conducted transmit power specifications.
Table 3-8: Radio Module WP8548 Conducted Transmit Power
Band Conducted Tx
Power (dBm)
Notes
HSPA+
Band 1 (IMT 2100 12.2 kbps)
Band 2 (HSPA+ 1900 12.2 kbps)
Band 5 (HSPA+ 850 12.2 kbps)
Band 6 (HSPA+ 800 12.2 kbps)
Band 8 (HSPA+ 900 12.2 kbps)
Band 19 (HSPA+ 850 12.2 kbps)
+23±1 Connectorized (Class 3)
GSM/GPRS/EDGE
GSM 850 +32±1 GMSK mode, connectorized
(Class 4, 2 W; 33 dBm)
E-GSM 900 +32±1
DCS 1800 +29±1 GMSK mode, connectorized
(Class 1, 1 W; 30 dBm)
PCS1900 +29±1
GSM 850 +26.5±1 8PSK mode, connectorized
(Class E2; 0.5 W; 27 dBm)
E-GSM 900 +26.5±1
DCS 1800 +25.5±1 8PSK mode, connectorized
(Class E2; 0.4 W; 26 dBm)
PCS1900 +25.5±1
Table 3-9: Radio Module WP7702 Conducted Transmit Power
Band Conducted
Tx Power (dBm)
Notes
LTE
Bands 1, 2, 3, 4, 5, 8, 12,
13, 17, 18, 19, 20, 26, 28
+23±1
GSM/GPRS/EDGE
GSM 850 +32±1 GMSK mode (Class 4; 2 W, 33 dBm)
+27±1 8PSK mode (Class E2; 0.5 W, 27 dBm)
E-GSM 900 +32±1 GMSK mode (Class 4; 2 W, 33 dBm)
+27±1 8PSK mode (Class E2; 0.5 W, 27 dBm)
DCS 1800 +29±1 GMSK mode (Class 1; 1 W, 30 dBm)
+26±1 8PSK mode (Class E2; 0.4 W, 26 dBm)
