Sigma DP2 User Manual

85
VIEWING IMAGES ON A TV
The DP2 camera can be connected to a television or a video
device using the provided AV cable, allowing the recorded images
to be viewed on the television monitor or recorded on video
recording media.
TO CONNECT THE CAMERA TO A
VIDEO DEVICE
1
Open the connector cover.
2
Connect the AV cable to the ＜ USB / AV ＞
terminal on the camera body.
3
Connect the yellow AV cable plug into the
video input terminal and the white plug
into the audio terminal of the TV
4
Turn on the camera and video device.
WARNING !!
• Please do not use any video cable other than the one provided with
your Sigma DP2 camera. Using other brands may cause damage.
TIP
• It is recommended that the camera be powered with the AC
adapter (optional) during television playback to avoid draining the
battery.
• The default mode for the video signal is NTSC. When connecting
the camera to a PAL device, the Video Mode setting in the Camera
Set-up menu must be changed. (See P.112)

Sigma DP2 Specifications

General

Megapixel	14.06 MP
Camera type	Compact camera
Sensor type	CMOS
Supported aspect ratios	3:2
Digital zoom	- x
Fixed focal length	24.2 mm
Interface	USB2.0, NTSC/PAL
Digital SLR	No
Built-in flash	Yes
Dimensions (WxDxH)	113.3 x 56.1 x 59.5 mm
Camera shutter speed	1/2000 - 15 s
Focus	TTL
Focus adjustment	Auto
Auto focusing (AF) modes	centre weighted auto focus, spot auto focus
Motion JPEG frame rate	30 fps
Maximum video resolution	320 x 240 pixels
Display diagonal	2.5 \
Display resolution (numeric)	230000 pixels
USB version	2.0
Product color	Black
Battery type	BP-31
Battery life (CIPA standard)	250 shots
Bundled software	Sigma PhotoPro
Compatible memory cards	mmc, sd
White balance	auto, custom modes, daylight, Fluorescent, Incandescent, Shade

Weight and Dimensions

Depth	56.1 mm
Width	113.3 mm
Height	59.5 mm
Weight	260 g
