Sigma DP2 User Manual

95
ROTATING IMAGES
It is possible to rotate the displayed image. The images’ new
orientation will be used in all views as well as in the Slideshow.
TIP
• Images rotated on the camera will be displayed in their rotated
orientation in SIGMA Photo Pro.
• Movie cannot be rotated.
ROTATE MENU
Rotate
Rotate the currently selected image 90 degrees to
the left (counterclockwise).
Rotate
Rotate the currently selected image 90 degrees to
the right (clockwise).
1
Use the button to select the image to be rotated in Contact Sheet
or Single-Image View.
2
Open [ Playback Menu](P.26) by pressing the button and
select [Rotate].
3
In Open Display, select the desired direction of rotation by pressing the
button.
4
Close [ Playback Menu] by pressing the button.
TIP
• To rotate an image 180 degrees, rotate it twice in the same
direction.
• To get an image back into its original orientation, rotate it in the
opposite direction.
• If the Rotate Menu was opened from Jump Mode, both “Rotate”
menu items will be unavailable.

Sigma DP2 Specifications

General

Megapixel	14.06 MP
Camera type	Compact camera
Sensor type	CMOS
Supported aspect ratios	3:2
Digital zoom	- x
Fixed focal length	24.2 mm
Interface	USB2.0, NTSC/PAL
Digital SLR	No
Built-in flash	Yes
Dimensions (WxDxH)	113.3 x 56.1 x 59.5 mm
Camera shutter speed	1/2000 - 15 s
Focus	TTL
Focus adjustment	Auto
Auto focusing (AF) modes	centre weighted auto focus, spot auto focus
Motion JPEG frame rate	30 fps
Maximum video resolution	320 x 240 pixels
Display diagonal	2.5 \
Display resolution (numeric)	230000 pixels
USB version	2.0
Product color	Black
Battery type	BP-31
Battery life (CIPA standard)	250 shots
Bundled software	Sigma PhotoPro
Compatible memory cards	mmc, sd
White balance	auto, custom modes, daylight, Fluorescent, Incandescent, Shade

Weight and Dimensions

Depth	56.1 mm
Width	113.3 mm
Height	59.5 mm
Weight	260 g
