Warnings / Errors
AG05 Date: 15.06.2016 Art. No. 85677 Mod. status 139/16 Page 22 of 64
Input of an odd gear transmission reduction value is possible according to the following
example:
Transmission reduction = 3.78
 Parameter 'ü – numerator': 378
 Parameter 'ü – denominator': 100
7 Warnings / Errors
7.1 Warnings
Warnings do not influence the operation of the positioning drive. Warnings disappear after
removing the cause.
Possible warnings:
 Battery voltage for absolute encoder is below limit  exchange battery within the next 6
months.
 Current limiting active.
7.2 Errors
Errors cause an immediate stop of the positioning drive. Error states are signalled via display.
Via interface errors can also be detected:
 The error messages are entered in the error memory in the order of their detection. The
last 10 error messages are displayed when the error memory is full.
 The cause of error can be tracked down with the help of the error codes.
7.2.1 Error codes
Display
Error codes
Error

0x00
No error

0x01
Timeout client

0x02
Timeout host

0x03
Check sum client

0x04
Check sum host

0x05
Define mismatch

0x06
Low battery voltage

0x07
Low control electronics voltage

0x08
Excess control electronics voltage

0x09
Excess power electronics voltage

0x0A
Output stage excess temperature
