Functional Description
AG05 Date: 15.06.2016 Art. No. 85677 Mod. status 139/16 Page 16 of 64
4.3.1.4 Limiting values
Menu


Sub-menu


Parameter
Description

Limit 1
Value range: -19999 … 99999
(see chapter 8: Parameter description  Parameter no. 15)

Limit 2
Value range: -19999 … 99999
(see chapter 8: Parameter description  Parameter no. 16)

Current limiting
Value range: 25 - 110
(see chapter 8: Parameter description  Parameter no. 29)

Contouring error limit
Value range: 1 - 30000
(see chapter 8: Parameter description  Parameter no. 28)
Table 6: Limiting values menu
4.3.1.5 Visualization
Menu


Sub-menu


Parameter
Description

Display orientation
Selection:
: 0°
: 180°
(see chapter 8: Parameter description  Parameter no. 45)

LED 2 orange function
Selection:
: Bus operation display
: Off
(see chapter 8: Parameter description  Parameter no. 39)

Red LED 1 function
Selection:
: Indication of the operating status
: Off
(see chapter 8: Parameter description  Parameter no. 40)
