Parameter description
AG05 Date: 15.06.2016 Art. No. 85677 Mod. status 139/16 Page 31 of 64
No.
Name
Selection
/ value
Default
Description
S
C
44
Direction
indication
function
0 - 2
0
Display:
The direction indicators show the key to be
pressed to arrive at the set position
window.
0 = On
1 = Inverted
2 = Off
S
3
45
Display
orientation
0 - 1
0
Display:
Display orientation
0 = 0°
1 = rotated by 180°
S
3
46
Program-
ming mode
configura-
tion
0 - 1
0
SIKONETZ5:
0 = no programming mode
1 = apply programming mode
Service protocol:
no function
S
5
47
Program-
ming mode
0 - 1
0
SIKONETZ5:
0 = Programming mode Off
1 = Programming mode On
Service protocol:
no function
-
1
48
PIN Change
0 - 99999
0
Display:
Required PIN to be able to change
parameters via keys and display.
S
3
49
Displayed
value 2
nd
display line
0 - 7
0
Display:
Parameter to be displayed in the 2
nd
line of
the display.
0 = Set point
1 = Output stage temperature
2 = Control voltage
3 = Output stage voltage
4 = Battery voltage
5 = Motor current
6 = Actual position
7 = Actual rotational speed
S
3
50
Output
stage
tempera-
ture
Read only
-
Output stage temperature:
Values in 1/10 °C
-
-
51
Voltage of
control
Read only
-
Control voltage:
Values in 1/10 V
-
-
52
Voltage of
output
stage
Read only
-
Output stage voltage:
Values in 1/10 V
-
-
53
Voltage of
battery
Read only
-
Battery voltage:
Values in 1/100 V
-
-
54
Motor
current
Read only
-
Motor current:
Values in mA
-
-
