9.6 Flow chart: Operating mode: Speed mode
The flow chart below illustrates the control in the rotational speed mode via service protocol
(see chapter 9: Service Protocol).
Fig. 9: Flow chart Totational speed mode service protocol
10 Communication via SIKONETZ5
10.1 Interface
Schnittstelle RS485
Available baud rates: 19.2 kBit / 57.6 kBit / 115.2 kBit
No parity, 8 data bits, 1 stop bit, no handshake
10.2 Data exchange
The protocol functions according to the master – slave principle.
The actuator acts as a slave. Every instance of communication must be initiated by the
master. When the master has sent a command telegram, the slave sends a reply telegram.
Broadcast commands are an exception, they remain always unanswered by the slave.
The protocol is optimized for cyclical data exchange. The relevant data such as set point and
actual value can be transferred between master and slave by a single telegram exchange.
Acknowledge error
command 'S11103'
Start
Supply voltage ON
Read status word
command 'R'
Operation enabled
SW = 00xx 0000 x000 x000
Enter target speed
command 'F0'
Enable target speed
command 'M'
Target speed enabled
SW = 01xx x000 000x x000
Stop travel order
command 'N' or 'O'
Change target speed
command 'F0'
Error
Status word bit 8 = '1'
SW = System status word
x = Bit can be '0' or '1'
