Functional Description
AG05 Date: 15.06.2016 Art. No. 85677 Mod. status 139/16 Page 14 of 64
Parameter
Description

Bus Timeout
Value range: 0 – 20
(see chapter 8: Parameter description  Parameter no. 35)
Table 3: Bus parameter menu
4.3.1.2 Positioning
Menu


Sub-menu


Parameter
Description

Pos window
Value range: 0 - 1000
(see chapter 8: Parameter description  Parameter no. 10)

Spindle pitch
Value range: 0 - 99999
(see chapter 8: Parameter description  Parameter no. 13)

Display divisor
Selection:
: 1
: 10
: 100
: 1000
(see chapter 8: Parameter description  Parameter no. 43)

Calibration value
Value range: -19999 … 99999
(see chapter 8: Parameter description  Parameter no. 14)

Selection:
: no calibration
: Execute calibration

Offset
Value range: -19999 … 99999
(see chapter 8: Parameter description  Parameter no. 32)

Sense of rotation
Selection:
: i sense of rotation (cw)
: e sense of rotation (ccw)
(see chapter 8: Parameter description  Parameter no. 18)
