Siko AG05 - Display, LED, and Control Parameters

Parameter description
AG05 Date: 15.06.2016 Art. No. 85677 Mod. status 139/16 Page 30 of 64
No.
Name
Selection
/ value
Default
Description
S
C
36
Write reply
parameter
to set point
0 - 8
1
SIKONETZ5:
This parameter defines the reply to the
Write set point command
0 = Set point
1 = Actual value
2 = Output stage temperature
3 = Control voltage
4 = Output stage voltage
5 = Battery voltage
6 = Motor current
7 = Actual position
8 = Actual rotational speed
Service protocol:
no function
S
4
37
Key enable
time
1 - 60
3
Display / key control:
Time in seconds the asterisk key must be
held down until menu can be entered or the
set point specification is enabled via
display.
S
3
38
Key
function
enable
0 - 1
0
Display / key control:
The access to inching mode 2, positioning
mode and rotational speed mode functions
via keys can be set with this parameter.
0 = all functions via key enabled
1 = all functions via key disabled
S
3
39
LED 2
orange
0 - 1
1
LED 2 orange function:
0 = Off
1 = Bus operation indication
S
3
40
LED 1 red
0 - 1
1
Red LED 1 function:
0 = Off
1 = Indication of the operating status
S
3
41
LED 1 green
0 - 1
1
Green LED 1 function:
0 = Off
1 = Indication of the operating status
S
3
42
Decimal
places
0 - 4
0
Display:
Input of decimal places
0 = 0
1 = 0.0
2 = 0.00
3 = 0.000
4 = 0.0000
S
3
43
Display
divisor
0 - 3
0
Display:
Divisor by which the display accuracy is
reduced compared with the measurement
resolution.
0 = 1
1 = 10
2 = 100
3 = 1000
S
3
