Functional Description
AG05 Date: 15.06.2016 Art. No. 85677 Mod. status 139/16 Page 17 of 64
Parameter
Description

Green LED 1 function
Selection:
: Indication of the operating status
: Off
(see chapter 8: Parameter description  Parameter no. 41)

Decimal places
Selection:
: 0
: 0.0
: 0.00
: 0.000
: 0.0000
(see chapter 8: Parameter description  Parameter no. 42)

Direction indication function
Selection:
: On
: inverted
: Off
(see chapter 8: Parameter description  Parameter no. 44)

Displayed value of 2
nd
display line
Selection:
: Set point
: Output stage temperature
: Control voltage
: Output stage voltage
: Battery voltage
: Motor current
: Actual position
: Actual rotational speed
(see chapter 8: Parameter description  Parameter no. 49)

Display test
Selection:
: no display test
: Start display test, pressing the key stops display test.
Table 7: Visualization menu
