Parameter description
AG05 Date: 15.06.2016 Art. No. 85677 Mod. status 139/16 Page 26 of 64
No.
Name
Selection
/ value
Default
Description
S
C
15
Limit 1
-9999999
to 9999999
99999
Operating mode: Positioning mode: Limit
1
Spindle pitch = 0: Values refer to increments
Spindle pitch > 0: Values refer to travelling
distance in 1/100 mm
If actuator's position is beyond the range
defined by limit 1 and limit 2 (travel
range), travelling will only be possible in
inching mode in the direction of the travel
range.
Notice! Limit monitoring is deactivated if
'limit 1' is equal 'limit 2'. Please note that
there is a jump of the actual position if the
resolution of the absolute encoder is
exceeded!
Operating mode: Speed mode:
irrelevant
S
1
16
Limit 2
-9999999
to 9999999
-19999
Operating mode: Positioning mode: Limit
2
Spindle pitch = 0: Values refer to increments
Spindle pitch > 0: Information refers to
travel distance in 1/100 mm
If actuator's position is beyond the range
defined by limit 1 and limit 2 (travel
range), travelling will only be possible in
inching mode in the direction of the travel
range.
Notice! Limit monitoring is deactivated if
'limit 1' is equal 'limit 2'. Please note that
there is a jump of the actual position if the
resolution of the absolute encoder is
exceeded!
Operating mode: Speed mode:
irrelevant
S
1
17
Delta inch
-1000000
to 1000000
720
Delta travelling distance with inching
operation 1:
Indicates the relative travelling distance.
positive value  positive travelling
direction
negative value  negative travelling
direction
Spindle pitch = 0: Values refer to increments
Spindle pitch > 0: Information refers to
travel distance in 1/100 mm
S
1
