Silex technology SD-300

Other manuals for Silex technology SD-300

Setup Guide2 pages

Questions and Answers

J
Jennifer HoustonAug 23, 2025
How to fix communication errors during Silex technology SD-300 Server configuration with Serial Device Server Setup?
- D
  Danielle EvansAug 23, 2025
  If you're experiencing communication errors while configuring your Silex technology Server with Serial Device Server Setup, here are some potential solutions: * Ensure that the SD-300/SD-320AN and your PC are on the same network segment, especially if you don't have a router. * If you're using a DHCP server, make sure your PC is set to 'Obtain an IP address automatically' in the Internet Protocol (TCP/IP) Properties. Alternatively, connect the PC and SD-300/SD-320AN to a standalone Ethernet Hub to isolate the issue. * If the SD-300/SD-320AN was previously used on another network, its settings might be preventing communication. Try resetting the SD-300/SD-320AN to its factory default settings.
R
Ruben EnglishAug 26, 2025
What to do if the Silex technology SD-300 IP address is already in use?
- M
  Margaret JosephAug 26, 2025
  If you suspect that the IP address assigned to your Silex technology Server (SD-300/SD-320AN) is being used by another device on the network, follow these steps: Turn off the SD-300/SD-320AN. Open the Windows Command Prompt and ping the IP address of the SD-300/SD-320AN. If you receive a reply while the SD-300/SD-320AN is off, another device is using the same IP address. Change the IP address of either the SD-300/SD-320AN or the other conflicting device.
A
Ashley NixonAug 28, 2025
How to check serial cable connection on Silex technology SD-300 Server?
- P
  Patrick RichardsAug 28, 2025
  To ensure proper connection between your Silex technology Server (SD-300/SD-320AN) and a serial device, verify that the serial cable is securely plugged into both the SD-300/SD-320AN and the serial device. If possible, try replacing the serial cable with a spare to rule out a faulty cable.
C
Curtis ChristensenAug 30, 2025
Why Silex technology SD-320AN Server turns on in wireless LAN mode?
- T
  Terry TranAug 30, 2025
  If your Silex technology SD-320AN Server is turning on in wireless LAN mode when connected to a 10BASE-T Ethernet HUB via a network cable, you can extend the time the device waits before recognizing a wired LAN connection. Here’s how: 1. Access the SD-320AN Web page and click 'WEB console' from the left menu. 2. Enter 'SET NW STARTDELAY 5' in the field and click Enter. 3. Enter 'SAVE' in the field and click Enter. 4. Click 'Restart' under Maintenance to restart SD-320AN.
D
Daniel SandersSep 7, 2025
What to do if communication error occurs when configuring Silex technology Server with Serial Device Server Setup?
- B
  bradballSep 7, 2025
  If a communication error occurs during configuration, consider these points: * The SD-300 may not be in the same network segment as your PC. Ensure they are in the same network segment during initial configuration. * In an environment with a DHCP server, the DHCP server may have configured the PC with an IP address from a different segment. Select 'Obtain an IP address automatically' in the Internet Protocol (TCP/IP) Properties of the PC. Alternatively, connect the PC and SD-300 to a standalone Ethernet Hub to test. * If the SD-300 has been used in another network, its settings may not allow communication with your PC. Reset the SD-300 to the factory default settings.
S
Stephanie StoneSep 12, 2025
What to do if Silex technology Server SD-300 IP address is in use?
- D
  Deborah MartinezSep 12, 2025
  If you suspect the IP address assigned to the SD-300 is being used by another device: * Turn off the SD-300 and open the Windows Command Prompt. Ping the SD-300's IP address. If you receive a reply while the SD-300 is off, another device is using the same IP address. Change the IP address of either the SD-300 or the other device.
C
Christina JohnsSep 14, 2025
What to do if the serial cable of Silex technology SD-300 is not plugged in correctly?
- K
  Kyle WhiteSep 14, 2025
  Verify that the serial cable is securely connected to both the SD-300 and the serial device. If possible, try using a different serial cable to rule out a faulty cable.
A
Amanda FlowersNov 17, 2025
Why is my Silex technology Server (SD-300/SD-320AN) not showing up in the Serial Device Server Setup search?
- S
  Stephanie TaylorNov 17, 2025
  There are several reasons why your Silex technology Server might not be showing up in the Serial Device Server Setup search: * There may be a connection, power, or operational issue with the SD-300/SD-320AN or the Ethernet Hub it's connected to. Check the LED status, replace cables, and reboot devices. * The SD-300/SD-320AN may not have finished starting up. It can take up to 30 seconds to be ready. Wait and then click 'Search' again. * The SD-300/SD-320AN and your PC might not be on the same network segment. Place them in the same network segment for initial configuration. * The SD-300/SD-320AN may have settings from a previous network that are interfering with communication. Reset it to the factory default settings. * Security software like a firewall could be blocking communi...
C
Caleb WoodardNov 19, 2025
What to do if serial devices are not displayed in SX Virtual Link for Silex technology SD-300 Server?
- T
  tonya64Nov 20, 2025
  If serial devices are not being displayed or are only temporarily displayed in SX Virtual Link for Serial Device Server with your Silex technology Server, consider the following: * Check the connection, power, and operation of the SD-300/SD-320AN and the Ethernet Hub. Look at the LED status, replace cables if needed, and reboot the devices. * Ensure the SD-300/SD-320AN has fully started up. It can take about 30 seconds. After that, refresh SX Virtual Link for Serial Device Server. * Security software, like a firewall, may be interfering. Add SX Virtual Link for Serial Device Server to your security software's exception list. * The IP address assigned to the SD-300/SD-320AN might not be able to communicate with your PC. Verify your PC's IP address using the Windows Command Prompt (...
M
Madison JohnsonDec 3, 2025
Why is my Silex technology Server SD-300 not displayed in the search results?

Summary

Introduction

1-1. Introduction

Provides an overview of the manual's purpose and structure.

1-2. Safety Instructions

Details critical safety warnings and precautions for using the device.

1-3. User Registration and Customer Services

Explains product registration and how to access customer support.

About SD-300;SD-320 AN

2-1. Package Contents

Lists all the items included in the product package.

2-2. Features

Describes the main features and capabilities of the SD-300/SD-320AN.

2-3. Parts and Functions

Identifies and explains the different parts and connectors of the device.

2-4. LED Lighting Pattern

Explains the meaning of different LED indicators on the device.

2-5. Hardware Specifications

Provides detailed technical specifications for the device's hardware components.

2-6. Software Specifications

Details the software features, supported protocols, and OS compatibility.

2-7. Wireless Interference Information

Discusses potential interference sources and advice for wireless operation.

2-8. Notes on Security

Highlights security considerations and potential risks associated with wireless LAN.

2-9. About OpenSSL License

Provides information regarding the OpenSSL license used in the software.

Software Overview

3-1. What is Serial Device Server Setup?

Explains the setup utility for configuring the serial device server.

3-2. What is SX Virtual Link for Serial Device Server?

Introduces the SX Virtual Link utility for managing serial devices.

3-3. Download the Utilities

Provides instructions and links for downloading necessary software utilities.

How to Configure (SD-300)

4-1. Necessary items for Setup

Lists the required hardware and cables for setting up the SD-300.

4-2. Power on

Details the steps for powering on the SD-300 device.

4-3. Configure Network Settings

Guides through the process of configuring network settings for the SD-300.

How to Configure (SD-320 AN)

5-1. Before Setup

Preparation steps and information needed before configuring the SD-320AN.

5-2. Necessary items for Setup

Lists the required hardware and cables for setting up the SD-320AN.

5-3. Power on

Details the steps for powering on the SD-320AN device.

5-4. Configure Network Settings

Guides through the process of configuring network settings for the SD-320AN.

5-5. Configure SD-320 AN Using Smart Wireless Setup

Explains how to configure the device using WPS and smart wireless setup.

How to Use

6-1. Link to Serial Device Using the Serial Device Connection Utility

Explains how to connect to serial devices using the SX Virtual Link utility.

6-2. Ecable Mode

Details how to use the Ecable Mode for serial device communication.

6-3. Raw TCP Connection Mode

Explains how to use the Raw TCP Connection Mode for serial data transfer.

6-4. Use Access Point Feature

Guides on how to configure and use the SD-320AN's Access Point feature.

Other Functions

7-1. Configure Using the SD-300;SD-320 AN Web Page

Describes how to configure advanced settings via the device's web interface.

7-2. Security Settings

Covers changing the password and configuring IP filter settings.

7-3. Maintenance

Provides instructions for rebooting and resetting the device to factory defaults.

7-4. Uninstall Application

Explains how to uninstall the SX Virtual Link for Serial Device Server software.

Troubleshooting

8-1. Problems During the Setup

Addresses common issues encountered during the initial device setup process.

8-2. Problems While Using SD-300;SD-320 AN

Troubleshoots issues that may occur during the normal operation of the device.

8-3. Wireless LAN Problems (SD-320 AN Only)

Provides specific troubleshooting steps for wireless LAN connectivity issues.
