Simrad is42 User Manual

Technical specification
Dimensions
Refer to "Dimensional drawing" on
page 73
Weight 0.32 kg (0.7 lbs)
Power consumption (@ 13.5
V)
Backlight OFF 1.35 W (100 mA)
Backlight MAX 2.16 W (160 mA)
Network load 4 LEN
Color Black
Display
Size 4.1" (diagonal). 4:3 Aspect ratio
Type
Transmissive TFT-LCD. White
LED backlight
Resolution 320 x 240 pixels
Illumination
White for day mode. Red, green,
blue or white for night mode
Environmental protection
Waterproof rating IPx7
Humidity 100% RH
Temperature
Operating -25° to +65ºC (-13°F to +149 ºF)
Storage -40° to +85ºC (-40°F to +185 ºF)
11
72
Technical specification | IS42 Operator Manual

Simrad is42 Specifications

General

Brand	Simrad
Model	is42
Category	Autopilot System
Language	English
