If you are îš¿nished using this feature and wanted to re-
move your USB device from the CDU, ensure that USB
Connected is changed to No and press the EDIT key once
more to exit EDIT mode before removing the device.
Please format your USB device using FAT32 îš¿le sys-
tem before use. Refer to page 192 for formatting
procedure and hardware compatibility list.
Wind
The receiver will display wind information in the NAV4
screen when connected to a NMEA 0183 sensor which
can provide the MWV or VWR sentence.
Data Input Port: 1 (default) or 2.
Wind Speed Unit: miles per hour, meters per second,
knots, kilometers per hour.
Alarm If No Data: Allows you to receive an audible and
visual alarm if NMEA 0183 data is not being received on
the data port at regular intervals (typically every few
seconds). The available choices are Yes (default) or No.
AWA Offset: Allows you to input a constant angle correc-
tion value.
AWS Correction Factor: Allows you to input a wind speed
correction factor.
Input Sentence: Specifies the NMEA 0183 data sentence
to read the depth data from. The available choices are
Any (default), MWV, or VWR sentence. It is better to
specify the appropriate sentence, because more than one
method of reporting wind may be available on the port.
