Simrad NSO evo2 - NSO Evo2 Marine Processor Box

6 |
NSO evo2 Overview | NSO evo2 Installation Manual
NSO evo2 Marine Processor Box
12
3
4
5 6
7
89
1 Ethernet Network ports with PoE (2x)
2 Ethernet Network port (1x)
3 Video Input BNC sockets (2x)
4 NMEA 2000 data port
5 NMEA 0183 & RS422 (2x)
6 Power connector
7 USB ports (2x)
8 HDMI sockets (2x)
9 SD Card slot
