Keyboard keys Function Remote controller keys
Menu
Opens the menu MENU
Ctrl + M
F1
Opens the Home page PAGES
Ctrl + P
F2
Opens the Chart page CHART
Ctrl + H
F3
Opens the Radar page RADAR
Ctrl + R
F4
Opens the Echo page ECHO
Ctrl + E
F5
Opens the Nav page NAV
Ctrl + N
F6
Opens the Instrument page INFO
Ctrl + I
F12 (press and hold)
Positions a MOB mark at
vessel position
MOB
Ctrl (double click)
Switches control to next
monitor connected to the
Processor unit (USB port
must be set to switchable)
DISPLAY
Ctrl + B
Centers the chart on vessel
position
VESSEL
Ctrl + D
Switches between panels on
a multi-panel page
WIN
Ctrl + G Opens the Goto menu GOTO
Ctrl + K
Places a waypoint at vessel/
cursor position
MARK
Ctrl + O
Opens the New Waypoint
dialog
PLOT
Ctrl + Q
Opens the System Controls
dialog
Power/Brightness
Ctrl + S
Switches the autopilot
system to STANDBY mode
STBY
Ctrl + U
Switches the autopilot
system to AUTO mode
AUTO
Ctrl + ;
Displays the Favorite panel as
pop-up on active page
PAGES (press and hold)
Ctrl + \
Take screenshot Power/Brightness + PAGES
PrintScn
Esc
Cancels changes and returns
to previous menu level
Closes an open menu
X
Enter
Activates/confirms current
selection
V or by pressing the Rotary
knob
Arrow keys
Move the cursor on the
panel, and maneuvers in the
menus/dialogs
Arrow keys
- and + Zoom - and +
12
Introduction | NSO evo2 Operator Manual
