Simrad NSS evo3 User Manual

The Audio panel
You activate the audio panel by activating the audio tile in the Instrument bar.
The control buttons, tools and options vary from one audio source to another as described
later in this chapter.
1 Audio source
2 Audio control buttons
3 Audio tile
4 Audio tools
Audio control buttons
Icon Tuner VHF DVD Playback
Select to display the list of available sources
Select to select previous/next
frequency
Press and hold to tune in a channel
Select to
rewind/play fast
forward
Select to select
previous/next
track
Select to select next/previous
favorite channel
N/A N/A
N/A N/A Select to start
N/A N/A Select to pause playback
Select to display the volume slider
106
Audio| NSS evo3 Operator Manual

Simrad NSS evo3 Specifications

General

Touchscreen	Yes
NMEA 0183 Connectivity	Yes
Operating System	Linux-based
Chartplotter	Yes
Radar Support	Yes
Waterproof Rating	IPX7
Operating Temperature	-15°C to +55°C
Display Size	9, 12, 16 inches
Screen Type	LCD
GPS	10 Hz built-in GPS receiver
Networking	Ethernet, Wi-Fi, Bluetooth
Sonar	CHIRP, StructureScan
Power Supply	12V DC
Video Input	2
Card Slots	2 x MicroSD
Processor	Quad-core processor
RAM	1GB
Internal Storage	8GB
Resolution	1280 x 800 (12")
