8
|
NSS overview | NSS Installation Manual
NSS7/NSS8 potential system example
Optional
accessory
HD RADAR
NEP-2
WEATHER
IMAGING
SONAR
USA Only
BROADBAND RADAR
Sirius satelite weather
and radio
HD Radar
2,4,6,10 or 25 kW
POWER
NETWORK
NETWORK NETWORK NETWORK NETWORK
NSS7 or NSS8
VIDEO /DATA
Video 1 (Red)
Video 2 (Green)
RX + Green
Blue
Yellow
Orange
TX +
TX -
RX -
NMEA 0183 Serial port
POWER
Red (FUSE)
Black
Yellow
Power Control
Ext. Alarm
12 or 24 V DC
Blue
+
_
ETHERNET SWITCH
3G / 4G
ECHO TRANSDUCER
Various inhull,
through hull, and
transom mount
options available
External GPS: ZG50
POWER: 12 V DC
Auto Pilot: Triton / AC12
Heading Sensor: RC42
Audio: SonicHub
Engines: NMEA2000
Digital Switching:
CZONE
Instruments: Triton
AIS: NAIS-400
NMEA2000
StructureScan HD
LSS-2 Transom Transducer
